西北大学学报(自然科学版)2023年8月,第53卷第4期,Aug.,2023,Vol.53,No.4JournalofNorthwestUniversity(NaturalScienceEdition)JNWU·可视化检测技术·基于LabVIEW的非接触式电阻抗层析成像系统研究Xi'anShiyouUniversity,Xi'an710065,China;王小鑫',张艳丽,白白萌,席炜,党博,胡红利?(1.西安石油大学陕西省油气井测控技术重点实验室,陕西西安710065;2.西安交通大学电力设备电气绝缘国家重点实验室,陕西西安710049)摘要非接触式电阻抗层析成像(non-contactelectricalimpedancetomography,NEIT)作为一种新型测试计量技术,具有无辐射、非接触和响应速度快的优点。传统电学层析成像(electricaltomography,ET)技术的图像重构部分通常在Matlab软件平台上进行离线成像,不利于工业现场的实时监测。针对上述问题,设计了一款基于LabVIEW的电阻抗层析成像系统,该系统可以实现数据的在线采集及实时成像。通过电阻抗测量系统提取阻抗信息的实部、虚部和相位分量,并结合LabVIEW编译的图像重构算法,分别对3种分量信息进行成像。为了提高重构精度,进一步利用主成分分析融合算法,对实部、虚部及相位成像结果进行图像融合。通过所搭建的两相流测试平台的验证,该系统可以有效用于不同介质分布下的两相流层析成像。关键词非接触式电阻抗层析成像;LabVIEW;两相流;图像融合中图分类号:TP183D0I:10.16152/j.cnki.xdxbzr.2023-04-007Researchofnon-contactelectricalimpedancetomographysystembasedonLabVIEWWANGXiaoxin',ZHANGYanli',BAIMeng',XIWei',DANGBo',HUHongli?(1.ShaanxiKeyLaboratoryofMeasurementandControlTechnologyforOilandGasWells,2.StateKeyLaboratoryofElectricalInsulationandPowerEquipment,Xi'anJiaotongUniversity,Xi'an710049,China)AbstractNon-contactelectricalimpedancetomography(NEIT),asanewtypeoftestandmeasurementtechnology,hastheadvantagesofnoradiation,non-contactandfastresponse.Theimagereconstructionpartoftraditionalelectricaltomographytechnologyisusuallyperformedoff-lineimagingontheMATLABsoftwareplatform,whichisnotconducivetoreal-timemonitoringinindustrialsites.Aimingattheaboveproblems,thispaperwilldesignaLabVIEW-basedelectricalimpedancetomographysystem,whichcanrealizeonlinedataacquisitionandreal-timeimaging.Throughtheimpedancemeasurementsystem,therealpart,imagin...
