IEC_PAS_61174-1-2021.pdf

IEC PAS 61174-1 Edition 1.0 2021-03 PUBLICLY AVAILABLE SPECIFICATION PRE-STANDARD Maritime navigation and radiocommunication equipment and systems Part 1:Route plan exchange format(RTZ)General requirements,methods of testing and required test results IEC PAS 61174-1:2021-03(en)colourinside THIS PUBLICATION IS COPYRIGHT PROTECTED Copyright 2021 IEC,Geneva,Switzerland All rights reserved.Unless otherwise specified,no part of this publication may be reproduced or utilized in any form or by any means,electronic or mechanical,including photocopying and microfilm,without permission in writing from either IEC or IECs member National Committee in the country of the requester.If you have any questions about IEC copyright or have an enquiry about obtaining additional rights to this publication,please contact the address below or your local IEC member National Committee for further information.IEC Central Office Tel.:+41 22 919 02 11 3,rue de Varemb infoiec.ch CH-1211 Geneva 20 www.iec.ch Switzerland About the IEC The International Electrotechnical Commission(IEC)is the leading global organization that prepares and publishes International Standards for all electrical,electronic and related technologies.About IEC publications The technical content of IEC publications is kept under constant review by the IEC.Please make sure that you have the latest edition,a corrigendum or an amendment might have been published.IEC publications search-webstore.iec.ch/advsearchform The advanced search enables to find IEC publications by a variety of criteria(reference number,text,technical committee,).It also gives information on projects,replaced and withdrawn publications.IEC Just Published-webstore.iec.ch/justpublished Stay up to date on all new IEC publications.Just Published details all new publications released.Available online and once a month by email.IEC Customer Service Centre-webstore.iec.ch/csc If you wish to give us your feedback on this publication or need further assistance,please contact the Customer Service Centre:salesiec.ch.IEC online collection-oc.iec.ch Discover our powerful search engine and read freely all the publications previews.With a subscription you will always have access to up to date content tailored to your needs.Electropedia-www.electropedia.org The worlds leading online dictionary on electrotechnology,containing more than 22 000 terminological entries in English and French,with equivalent terms in 18 additional languages.Also known as the International Electrotechnical Vocabulary(IEV)online.IEC PAS 61174-1 Edition 1.0 2021-03 PUBLICLY AVAILABLE SPECIFICATION PRE-STANDARD Maritime navigation and radiocommunication equipment and systems Part 1:Route plan exchange format(RTZ)General requirements,methods of testing and required test results INTERNATIONAL ELECTROTECHNICAL COMMISSION ICS 47.020.70;47.060 ISBN 978-2-8322-9482-6 Registered trademark of the International Electrotechnical Commission Warning!Make sure that you obtained this publication from an authorized distributor.colourinside 2 IEC PAS 61174-1:2021 IEC 2021 CONTENTS FOREWORD.4 INTRODUCTION.6 1 Scope.7 2 Normative references.7 3 Terms,definitions and abbreviated terms.7 3.1 Terms and definitions.7 3.2 Abbreviated terms.7 4 Requirements.8 4.1 General.8 4.2 RTZP data container.9 4.3 High-level description of the RTZ format.10 4.4 Adaption to third-party extensions and handling of optional data.10 4.4.1 Generic idea.10 4.4.2 Unique identification of a waypoint.10 4.4.3 Creation of new waypoints.11 4.4.4 Change of geographic data for a waypoint.11 4.4.5 Waypoint removal.11 4.4.6 Waypoint modification.11 4.5 Detailed RTZ format description.11 4.5.1 File components.11 4.5.2 Route node description.11 4.5.3 RouteInfo node description.12 4.5.4 Waypoints node description.13 4.5.5 DefaultWaypoint node description.13 4.5.6 Waypoint node description.14 4.5.7 Storing date and time for legs.15 4.5.8 Schedules node description.16 4.5.9 Schedule node description.16 4.5.10 Extensions node description.18 4.5.11 Extension node description.19 4.6 XML schema to be met by RTZ route files.19 4.6.1 RTZ schema version 1.0.19 4.6.2 RTZ schema version 1.2.19 4.7 Basic RTZ v1.0 route example.19 4.8 RTZ v1.2 test files.21 5 Methods of testing and required test results.21 5.1 General.21 5.2 User manual.21 5.3 Schema compliance.21 5.4 RTZP data container.22 5.5 Revision attribute.22 5.6 Schedules.22 5.7 Manufacturer extensions and handling of optional data.23 5.8 Default data.23 5.9 Application of leg element values.23 Annex A(normative)RTZ schema version 1.2.24 IEC PAS 61174-1:2021 IEC 2021 3 Annex B(normative)RTZ v1.2 test files.48 B.1 RTZ v1.2 with minimum mandatory elements.48 B.2 RTZ v1.2 with leg elements.48 B.3 RTZ v1.2 with all optional elements and attributes.48 B.4 RTZ v1.2 not fully conforming to schema(errors).48 B.5 RTZ v1.2 in RTZP data container.49 B.6 RTZ v1.2 with extensions from 3rd party manufacturer.49 B.7 RTZ v1.2 using revision attribute.49 B.8 RTZ 1.2
