IEC 60617 database snapshot created on 2001-12-12 Copyright 2001 IEC,Geneva,Switzerland.All rights reserved-Not for reproduction or distribution S00001Name:Connection,general symbolStatus:ReleasedDate of release:2001-07-01Publication ref:IEC 60617-3(ed.2.0)03-01-01Usage:conductor;cable;line;transmission pathKeywords:cables,conductors,connections,lines,transmission pathsApplied in:S00004,S00005,S00050,S00051,S00052,S00054,S00407,S00408,S00409,S00410,S00411,S00412,S00413,S00414,S00415,S00416,S00417,S00418,S00423,S00425,S00437,S00439,S00444,S00445,S00446,S00447,S00448,S00449,S00531,S00592,S00826,S01080,S01081,S01082,S01083,S01084,S01086,S01138,S01140,S01141,S01142,S01143,S01145,S01148,S01149,S01150,S01151,S01185,S01318,S01377,S01378Application notes:A00193,A00194Shape class:Lines Function class:W Guiding or transportingApplication class:Circuit diagrams,Connection diagrams,Function diagrams,Installation diagrams,Network maps,Overview diagramsRemarks:See also symbol S00058.IEC 60617 database snapshot created on 2001-12-12 Copyright 2001 IEC,Geneva,Switzerland.All rights reserved-Not for reproduction or distribution S00002Name:Group of connections(number of connections indicated)Status:ReleasedDate of release:2001-07-01Publication ref:IEC 60617-3(ed.2.0)03-01-02Keywords:conductors,connectionsForm:Form 1Other forms:S00003Applied in:S00025,S00449,S00852,S00854,S00856,S00858,S00860,S00862,S00864,S00866,S00868,S00870,S00872,S00874,S00876,S00880,S00882,S00884,S00886,S00888,S00890,S01087,S01088,S01089,S01091,S01093Applying:S00058Application notes:A00192,A00193,A00194Shape class:Lines Function class:W Guiding or transportingApplication class:Circuit diagrams,Connection diagrams,Function diagrams,Installation diagrams,Network maps,Overview diagramsRemarks:Three connections shown.IEC 60617 database snapshot created on 2001-12-12 Copyright 2001 IEC,Geneva,Switzerland.All rights reserved-Not for reproduction or distribution S00003Name:Group of connections(number of connections indicated)Status:ReleasedDate of release:2001-07-01Publication ref:IEC 60617-3(ed.2.0)03-01-03Keywords:conductors,connectionsForm:Form 2Other forms:S00002Applied in:S00024,S00027,S00053,S00055,S00294,S00295,S00888,S00890,S01092,S01277,S01285,S01323,S01324Applying:S00058Application notes:A00192,A00193,A00194Shape class:Characters,Lines Function class:W Guiding or transportingApplication class:Circuit diagrams,Connection diagrams,Function diagrams,Installation diagrams,Network maps,Overview diagramsRemarks:Three connections shown.IEC 60617 database snapshot created on 2001-12-12 Copyright 2001 IEC,Geneva,Switzerland.All rights reserved-Not for reproduction or distribution S00004Name:Direct current circuitStatus:ReleasedDate of release:2001-07-01Publication ref:IEC 60617-3(ed.2.0)03-01-04Keywords:conductors,connectionsApplying:S00001;S01401Application notes:A00193,A00194Shape class:Characters,Lines Function class:W Guiding or transportingApplication class:Circuit diagrams,Connection diagramsRemarks:110 V,two aluminium conductors of 120 mm2IEC 60617 database snapshot created on 2001-12-12 Copyright 2001 IEC,Geneva,Switzerland.All rights reserved-Not for reproduction or distribution S00005Name:Three-phase circuitStatus:ReleasedDate of release:2001-07-01Publication ref:IEC 60617-3(ed.2.0)03-01-05Keywords:conductors,connectionsApplied in:S00314Applying:S00001;S01403Application notes:A00193,A00194Shape class:Characters,Lines Function class:W Guiding or transportingApplication class:Circuit diagrams,Connection diagrams,Function diagramsRemarks:50 Hz,400 V,three conductors of 120 mm(2),with neutral of 50 mm(2).3N may be replaced by 3+N.IEC 60617 database snapshot created on 2001-12-12 Copyright 2001 IEC,Geneva,Switzerland.All rights reserved-Not for reproduction or distribution S00006Name:Flexible connectionStatus:ReleasedDate of release:2001-07-01Publication ref:IEC 60617-3(ed.2.0)03-01-06Keywords:conductors,connectionsApplied in:S01147Shape class:Depicting shapesFunction class:W Guiding or transportingApplication class:Circuit diagrams,Connection diagrams,Function diagrams,Installation diagrams,Network maps,Overview diagramsIEC 60617 database snapshot created on 2001-12-12 Copyright 2001 IEC,Geneva,Switzerland.All rights reserved-Not for reproduction or distribution S00007Name:Screened conductorStatus:ReleasedDate of release:2001-07-01Publication ref:IEC 60617-3(ed.2.0)03-01-07Keywords:conductors,connectionsApplied in:S00013,S00783,S00791Application notes:A00001Shape class:Circles,Lines Function class:W Guiding or transportingApplication class:Circuit diagrams,Connection diagrams,Function diagrams,Installation diagrams,Network maps,Overview diagramsIEC 60617 database snapshot created on 2001-12-12 Copyright 2001 IEC,Geneva,Switzerland.All rights reserved-Not for reproduction or distribution S00008Name:Twisted connectionStatus:ReleasedDate of release:2001-07-01Publication ref:IEC 60617-3(ed.2.0)03-01-08Keywords:conductors,connectionsApplication notes:A00001Sh
