Designation:F220619An American National StandardStandard Specification forFabricated Fittings of Butt-Fused Polyethylene(PE)1This standard is issued under the fixed designation F2206;the number immediately following the designation indicates the year oforiginal adoption or,in the case of revision,the year of last revision.A number in parentheses indicates the year of last reapproval.Asuperscript epsilon()indicates an editorial change since the last revision or reapproval.1.Scope*1.1 This specification establishes requirements for fabri-cated fittings intended for use with outside-diameter controlledpolyethylene pipe and tubing.These fittings are manufacturedby heat-fusion joining shape-modified polyethylene compo-nents prepared from pipe,molded fittings,sheet,billet,orblock.Included are requirements for materials,design,workmanship,minimum dimensions,marking,test methods,and quality control.1.2 Pressure rating of the fabricated-fitting design is beyondthe scope of this standard and shall be established by the fittingmanufacturer.1.3 This specification includes requirements for both el-evated temperature pressure-tests at the pressure rating estab-lished by the fitting manufacturer.1.4 The pressure-tests requirements are specified by thefittingsequivalent(E)DR.The EDR specified is the DR of thepiping system for which the fabricated fitting is intended to bebutt-fused.1.5 The text of this standard references notes and footnoteswhich provide explanatory material.These notes and footnotes(excluding those in tables and figures)shall not be consideredas requirements of the standard.1.6 UnitsThe values stated in inch-pound units are to beregarded as standard.The values given in parentheses aremathematical conversions to SI units which are provided forinformation only and are not considered standard.1.7 The following safety hazards caveat pertains only to thetest methods portion,Section 9,of this specification.Thisstandard does not purport to address all of the safety concerns,if any,associated with its use.It is the responsibility of the userof this standard to establish appropriate safety,health,andenvironmental practices and determine the applicability ofregulatory limitations prior to use.1.8 This international standard was developed in accor-dance with internationally recognized principles on standard-ization established in the Decision on Principles for theDevelopment of International Standards,Guides and Recom-mendations issued by the World Trade Organization TechnicalBarriers to Trade(TBT)Committee.2.Referenced Documents2.1 ASTM Standards:2D1600 Terminology forAbbreviated Terms Relating to Plas-ticsD2122 Test Method for Determining Dimensions of Ther-moplastic Pipe and FittingsD2513 Specification for Polyethylene(PE)Gas PressurePipe,Tubing,and FittingsD3035 Specification for Polyethylene(PE)Plastic Pipe(DR-PR)Based on Controlled Outside DiameterD3261 Specification for Butt Heat Fusion Polyethylene(PE)Plastic Fittings for Polyethylene(PE)Plastic Pipe andTubingF412 Terminology Relating to Plastic Piping SystemsF714 Specification for Polyethylene(PE)Plastic Pipe(DR-PR)Based on Outside DiameterF2619/F2619M Specification for High-Density Polyethylene(PE)Line PipeF2880 Specification For Lap-Joint Type Flange Adapters forPolyethylene Pressure Pipe in Nominal Pipe Sizes 3/4 in.to 65 in.F3034 Specification for Billets made by Winding MoltenExtruded Stress-Rated High Density Polyethylene(HDPE)2.2 Federal Standards:3Fed.Std.No.123 Marking for Shipment(Civil Agencies)OPS Part 192 Title 49,Code of Federal Regulations2.3 Military Standard:3MIL-STD-129 Marking for Shipment and Storage2.4 ANSI/NSF Standard:4ANSI/NSF 61 for Drinking Water System ComponentsHealth Effects1This specification is under the jurisdiction of ASTM Committee F17 on PlasticPiping Systems and is the direct responsibility of Subcommittee F17.10 on Fittings.Current edition approved Jan.15,2019.Published January 2019.Originallyapproved in 2002.Last previous edition approved in 2014 as F2206 14.DOI:10.1520/F2206-19.2For referenced ASTM standards,visit the ASTM website,www.astm.org,orcontact ASTM Customer Service at serviceastm.org.For Annual Book of ASTMStandards volume information,refer to the standards Document Summary page onthe ASTM website.3DLA Document Services Building 4/D 700 Robbins Avenue Philadelphia,PA19111-5094 http:/quicksearch.dla.mil/4Available from American National Standards Institute(ANSI),25 W.43rd St.,4th Floor,New York,NY 10036,http:/www.ansi.org.*A Summary of Changes section appears at the end of this standardCopyright ASTM International,100 Barr Harbor Drive,PO Box C700,West Conshohocken,PA 19428-2959.United StatesThis international standard was developed in accordance with internationally recognized principles on standardization established in the Decision on Principles for theDevelopment of International Standards,Guides and Recommendations issued by the World Trade Organization Technical Barriers to Trade(TBT)Committee.1 2.5 Plas
