Designation:F82293(Reapproved 2010)An American National StandardStandard Specification forChest of Drawers(Chiffonier),Steel,Marine1This standard is issued under the fixed designation F822;the number immediately following the designation indicates the year of originaladoption or,in the case of revision,the year of last revision.Anumber in parentheses indicates the year of last reapproval.Asuperscriptepsilon()indicates an editorial change since the last revision or reapproval.1.Scope1.1 This specification covers the construction of marinechests of drawers(chiffoniers)of steel construction to be usedin staterooms and other spaces.1.2 Values stated in inch-pound units are to be regarded asthe standard.The metric equivalents,given in parentheses,areprovided for information only.2.Referenced Documents2.1 ASTM Standards:2A366/A366M Specification for Commercial Steel(CS)Sheet,Carbon,(0.15 Maximum Percent)Cold-Rolled(Withdrawn 2000)3D907 Terminology of AdhesivesF825 Specification for Drawers,Furniture,Marine,SteelF826 Specification for Tops,Furniture,Marine,Steel2.2 American Institute of Steel Construction Manual:AISC Wire and Sheet Metal Gages Equivalent Thicknessin Decimals of an Inch,U.S.Standard Gauge for UncoatedHot and Cold Rolled Sheets43.Terminology3.1 Definitions of Terms Specific to This Standard:3.1.1 chest of drawers(chiffonier)a chest of drawers withfour drawers.All four drawers may be of the same size.4.Ordering Information4.1 Orders for items purchased under this specification shallinclude the following information:4.1.1 Quantity.4.1.2 Paint:4.1.2.1 ColorPurchaser shall pick from manufacturerssamples or submit sample chip of color desired.4.1.2.2 Manufacturers standard baked enamel will be fur-nished unless otherwise required and indicated by the pur-chaser.4.1.3 Options for Tops:4.1.3.1 Unlessotherwisespecifiedintheorderingdocuments,the top supplied by the furniture manufacturer maybe,at his option,Type I,II,III,or IV in accordance withSpecification F826.4.1.3.2 Color or pattern of top covering material shall bespecified.4.1.4 Options for Drawers:4.1.4.1 Padlock eyes shall be furnished on each drawerwhen specified in ordering documents.This security device isnormally used in crew living spaces.4.1.4.2 Drawer locks shall be furnished when specified inordering documents.Master keying of drawer locks will not beprovided unless required and defined by the ordering docu-ments.Instead,each drawer lock will be keyed differently.SeeSpecification F825 for lock description.4.1.4.3 A security panel between the two middle drawers toprovide two secure two-drawer storage areas for two crewmembers is only furnished when specified in ordering docu-ments.All four drawers in this type chest will be of same size.4.1.5 If the total weight of the chest of drawers is required,it shall be requested by the purchaser.5.Materials and Manufacture5.1 For typical design,see Fig.1.5.2 Sheet metal shall be in accordance with SpecificationA366/A366M,commercial quality.5.2.1 Minimum sheet metal thicknesses shall be:5.2.1.1 Sides and front rails 18 USSG(0.0478 in.or 1.2mm).5.2.1.2 Back 20 USSG(0.0359 in.or 0.9 mm).5.2.1.3 Base frame 16 USSG(0.0598 in.or 1.5 mm).5.3 Joining of Metal Components:5.3.1 Metal components shall be joined by welding orgluing with a structural adhesive as defined in TerminologyD907.The back panel may be riveted to the case providedrivets are not visible after installation.1This specification is under the jurisdiction of ASTM Committee F25 on Shipsand Marine Technology and is the direct responsibility of Subcommittee F25.03 onOutfitting and Deck Machinery.Current edition approved March 1,2010.Published April 2010.Originallyapproved in 1983.Last previous edition approved in 2004 as F822 93(2004).DOI:10.1520/F0822-93R10.2For referenced ASTM standards,visit the ASTM website,www.astm.org,orcontact ASTM Customer Service at serviceastm.org.For Annual Book of ASTMStandards volume information,refer to the standards Document Summary page onthe ASTM website.3The last approved version of this historical standard is referenced onwww.astm.org.4Available from American Institute of Steel Construction(AISC),One E.Wacker Dr.,Suite 700,Chicago,IL 60601-2001,http:/www.aisc.org.Copyright ASTM International,100 Barr Harbor Drive,PO Box C700,West Conshohocken,PA 19428-2959.United States1 5.3.2 Joining shall be adequate to prevent racking of chestduring handling.5.3.3 Spotwelds shall be spaced approximately 3 in.(76mm)on centers.5.3.4 Visible spotwelds,higher than the general surface ofthe adjacent metal,shall be ground flush.5.3.5 Visible spotweld depressions shall be spot filled andsanded flush.5.4 Side panels shall be suitably stiffened to prevent buck-ling or oil-canning.5.5 Sound deadening shall be vermin proof and applied toback and inner face of sides of chest.Location and thickness ofapplied sound deadener shall be as required to sound-deadenchest.5.6 Top shall be manufactured in accordance with Specifi-cation F826.5.7 Draw
