Designation:F154515aStandard Specification forPlastic-Lined Ferrous Metal Pipe,Fittings,and Flanges1This standard is issued under the fixed designation F1545;the number immediately following the designation indicates the year oforiginal adoption or,in the case of revision,the year of last revision.A number in parentheses indicates the year of last reapproval.Asuperscript epsilon()indicates an editorial change since the last revision or reapproval.1.Scope*1.1 This specification covers factory-made plastic-lined fer-rous metal pipe,fittings,and flanges intended primarily forconveying corrosive fluids.Requirements for materials,workmanship,dimensions,design,fabrication,working pres-sureandtemperatures,testmethods,qualificationrequirements,and markings are included.1.1.1 This specification does not define the suitability ofdifferent liner materials to various chemical and operatingenvironments.Refer to the manufacturers chemical resistancedata for suitability recommendations.1.1.2 This specification does not include products coatedwith plastics.1.2 This specification covers plastic-lined pipe,flanges,andfittings as listed in Table 1.Pressure limitations shall be inaccordance with ASME B16 Standards,except reduced pres-sure limitations may be established by the manufacturer,considering both pressure and temperature limitations of theferrous metal housing and the sealing ability of the liner.NOTE1In this specification,propylene plastics cover those materialsdefined as both polypropylene plastics and propylene plastics in Termi-nology F412.Both materials are identified as“PP”on the product.Notethat this is at variance with Terminology D1600,where“PP”is theabbreviation for polypropylene.1.3 The plastic-lined flanged pipe and fitting assemblies arelimited to temperatures shown in Table 2.End users shouldconsult with manufacturers as to the likely result of using aparticular lined piping component at temperatures below therated minimum.NOTE2The temperature limitations are based on noncorrosive testconditions.Use in specific aggressive environments may alter temperaturelimitations.In such instances,specific temperature limits shall be estab-lished by mutual agreement between the purchaser and the manufacturer.1.4 The values stated in inch-pound units are to be regardedas standard.The values given in parentheses are mathematicalconversions to SI units that are provided for information onlyand are not considered standard.1.5 This standard does not purport to address all of thesafety concerns,if any,associated with its use.It is theresponsibility of the user of this standard to establish appro-priate safety and health practices and determine the applica-bility of regulatory limitations prior to use.2.Referenced Documents2.1 ASTM Standards:2A48/A48M Specification for Gray Iron CastingsA53/A53M Specification for Pipe,Steel,Black and Hot-Dipped,Zinc-Coated,Welded and SeamlessA105/A105M Specification for Carbon Steel Forgings forPiping ApplicationsA106/A106M Specification for Seamless Carbon Steel Pipefor High-Temperature ServiceA126 Specification for Gray Iron Castings for Valves,Flanges,and Pipe FittingsA135/A135M Specification for Electric-Resistance-WeldedSteel PipeA182/A182M Specification for Forged or Rolled Alloy andStainless Steel Pipe Flanges,Forged Fittings,and Valvesand Parts for High-Temperature ServiceA216/A216M Specification for Steel Castings,Carbon,Suit-able for Fusion Welding,for High-Temperature ServiceA234/A234M Specification for Piping Fittings of WroughtCarbon Steel and Alloy Steel for Moderate and HighTemperature ServiceA278/A278M Specification for Gray Iron Castings forPressure-Containing Parts for Temperatures Up to 650F(350C)A312/A312M Specification for Seamless,Welded,andHeavily Cold Worked Austenitic Stainless Steel PipesA351/A351M Specification for Castings,Austenitic,forPressure-Containing PartsA395/A395M SpecificationforFerriticDuctileIronPressure-Retaining Castings for Use at Elevated Tempera-turesA403/A403M Specification for WroughtAustenitic StainlessSteel Piping Fittings1This specification is under the jurisdiction of ASTM Committee F17 on PlasticPiping Systems and is the direct responsibility of Subcommittee F17.11 onComposite.Current edition approved May 1,2015.Published June 2015.Originallyapproved in 1995.Last previous edition approved in 2015 as F1545 15.DOI:10.1520/F154515A.2For referenced ASTM standards,visit the ASTM website,www.astm.org,orcontact ASTM Customer Service at serviceastm.org.For Annual Book of ASTMStandards volume information,refer to the standards Document Summary page onthe ASTM website.*A Summary of Changes section appears at the end of this standardCopyright ASTM International,100 Barr Harbor Drive,PO Box C700,West Conshohocken,PA 19428-2959.United States1 A513/A513M Specification for Electric-Resistance-WeldedCarbon and Alloy Steel Mechanical TubingA536 Specification for Ductile Iron CastingsA587 Specification for Electric-Resistance-Welded Low-Carbon Steel Pipe for
