Designation:F134791(Reapproved 2012)An American National StandardStandard Specification forManually Operated Fueling Hose Reels1This standard is issued under the fixed designation F1347;the number immediately following the designation indicates the year oforiginal adoption or,in the case of revision,the year of last revision.A number in parentheses indicates the year of last reapproval.Asuperscript epsilon()indicates an editorial change since the last revision or reapproval.This standard has been approved for use by agencies of the U.S.Department of Defense.1.Scope1.1 This specification covers manually operated fuelinghose reels for use with collapsible and noncollapsible hose.1.2 The values stated in inch-pound units are to be regardedas standard.The SI units given in parentheses are for informa-tion only.1.3 The following precautionary caveat pertains only to thetest methods portion,Section 12 of this specification:Thisstandard does not purport to address all of the safety concerns,if any,associated with its use.It is the responsibility of the userof this standard to establish appropriate safety and healthpractices and determine the applicability of regulatory limita-tions prior to use.2.Referenced Documents2.1 ASTM Standards:2B148 Specification for Aluminum-Bronze Sand CastingsD3006 Specification for Polyethylene Plastic Pressure-Sensitive Electrical Insulating TapeD3951 Practice for Commercial Packaging2.2 Military Specifications:3MIL-S-901 Shock Test,H.I.(High-Impact);ShipboardMachinery,Equipment and Systems,Requirements forMIL-T-16366 Terminals,Electric Lug and ConductorSplices,Crimp StyleMIL-H-17902 Hose,End Fittings and Hose Assemblies,Synthetic Rubber,Aircraft FuelsMIL-F-20042 Flanges,Pipe and Bulkhead,Bronze(SilverBrazing)MIL-P-24441 Epoxy-Polyamide Primer2.3 Military Standard:3MIL-STD-130 Identification Marking of U.S.Military Prop-erty3.Classification3.1 Fueling hose reels shall be of one of the following typesas specified:3.1.1 Type 1For 150 ft(46 m)of collapsible 212-in.(65-mm)hose.3.1.2 Type 2For 150 ft(46 m)of noncollapsible 112-in.(38-mm)hose or 100 ft(30 m)of noncollapsible 2-in.(50-mm)hose.3.1.3 Type 3For 150 ft(46 m)of noncollapsible 112-in.(38-mm)hose or for 150 ft(46 m)of collapsible 212-in.(65-mm)hose.3.1.4 Type 4Capacity as specified by purchaser.4.Ordering Information4.1 Orders for material under this specification shall includethe following information:4.1.1 Title,number,and year of issue of this specification,4.1.2 Type of hose reel including hose size and type(see3.1),(length of hose for Type 4),4.1.3 Whether right-or left-hand reels are required(see 6.5),4.1.4 Flange inlet thickness and bolt hole dimensions(see6.7),4.1.5 Drawings required(see 9.1),4.1.6 The number of samples to be inspected and tested(see11.2),4.1.7 Certification,if required(see 15.1),4.1.8 Test report,if required(see 15.1),and4.1.9 Applicability of supplementary requirements.5.Materials and Manufacture5.1 Except as otherwise specified herein,the hose reels shallbe constructed of aluminum,aluminum bronze,or othersuitable nonsparking materials.All fittings conveying aromaticfuels through the hose reel shall be made of aluminum bronzein accordance with Specification B148,copper alloy UNS No.C95300.To prevent deterioration in sea atmosphere,aluminumparts should not contact brass or bronze;however,where suchaluminum parts come in contact with brass or bronze,they1This specification is under the jurisdiction of ASTM Committee F25 on Shipsand Marine Technology and is the direct responsibility of Subcommittee F25.07 onGeneral Requirements.Current edition approved May 1,2012.Published May 2012.Originallyapproved in 1991.Last previous edition approved in 2006 as F1347 91(2006).DOI:10.1520/F1347-91R12.2For referenced ASTM standards,visit the ASTM website,www.astm.org,orcontact ASTM Customer Service at serviceastm.org.For Annual Book of ASTMStandards volume information,refer to the standards Document Summary page onthe ASTM website.3Available from Standardization Documents Order Desk,DODSSP,Bldg.4,SectionD,700RobbinsAve.,Philadelphia,PA19111-5098,http:/dodssp.daps.dla.mil.Copyright ASTM International,100 Barr Harbor Drive,PO Box C700,West Conshohocken,PA 19428-2959.United States1 shall be protected by adhesive-backed insulating tape,Speci-fication D3006.All aluminum parts shall be given a coat ofepoxy-polyamide primer.6.Construction6.1 Reel and Drum AssemblyThe hose reel shall be of adurable,rigid construction,as light in weight and compact aspracticable.The drum assembly(drum,reel sides,and itsreinforcements)shall withstand the hose pull without distortionor collapse and shall be capable of withstanding some sidewayshose pull without undue distortions.The construction of thecompleted drum assembly shall be such that disassembly canbe readily accomplished with standard tools.When bolteddown to a true flat surface,the shaft and rotating sealcenterlines shall be in true alignment and the drum assemblyshall turn without bindi
