Designation:B57517Standard Specification forLow-Carbon Nickel-Chromium-Molybdenum,Low-CarbonNickel-Chromium-Molybdenum-Copper,Low-Carbon Nickel-Chromium-Molybdenum-Tantalum,Low-Carbon Nickel-Chromium-Molybdenum-Tungsten,and Low-Carbon Nickel-Molybdenum-Chromium Alloy Plate,Sheet,and Strip1This standard is issued under the fixed designation B575;the number immediately following the designation indicates the year oforiginal adoption or,in the case of revision,the year of last revision.A number in parentheses indicates the year of last reapproval.Asuperscript epsilon()indicates an editorial change since the last revision or reapproval.This standard has been approved for use by agencies of the U.S.Department of Defense.1.Scope*1.1 This specification2covers plate,sheet,and strip oflow-carbon nickel-chromium-molybdenum alloys(UNSN10276,N06022,N06455,N06035,N06044,UNS N06058,UNS N06059),3low-carbon nickel-chromium-molybdenum-copper alloy(UNS N06200),low-carbon nickel-molybdenum-chromium(UNS N10362),low-carbon nickel-chromium-molybdenum-tantalum alloy(UNS N06210),and low-carbonnickel-chromium-molybdenum-tungsten alloy(UNS N06686)as shown in Table 1,for use in general corrosive service.1.2 The following products are covered under this specifi-cation:1.2.1 Sheet and StripHot or cold rolled,solution annealed,and descaled unless solution anneal is performed in an atmo-sphere yielding a bright finish.1.2.2 PlateHot or cold rolled,solution annealed,anddescaled.1.3 The values stated in inch-pound units are to be regardedas standard.The values given in parentheses are mathematicalconversions to SI units that are provided for information onlyand are not considered standard.1.4 This standard does not purport to address all of thesafety concerns,if any,associated with its use.It is theresponsibility of the user of this standard to become familiarwith all hazards including those identified in the appropriateSafety Data Sheet(SDS)for this product/material as providedby the manufacturer,to establish appropriate safety and healthpractices,and determine the applicability of regulatory limi-tations prior to use.1.5 This international standard was developed in accor-dance with internationally recognized principles on standard-ization established in the Decision on Principles for theDevelopment of International Standards,Guides and Recom-mendations issued by the World Trade Organization TechnicalBarriers to Trade(TBT)Committee.2.Referenced Documents2.1 ASTM Standards:4B906 Specification for General Requirements for Flat-Rolled Nickel and Nickel Alloys Plate,Sheet,and StripE112 Test Methods for Determining Average Grain SizeE140 Hardness Conversion Tables for Metals RelationshipAmong Brinell Hardness,Vickers Hardness,RockwellHardness,Superficial Hardness,Knoop Hardness,Sclero-scope Hardness,and Leeb HardnessE527 Practice for Numbering Metals and Alloys in theUnified Numbering System(UNS)3.Terminology3.1 Definitions of Terms Specific to This Standard:3.1.1 cold-rolled plate,nmaterial316to38in.(4.76 to9.52 mm),inclusive,in thickness.3.1.2 hot-rolled plate,nmaterial316in.(4.76 mm)andover in thickness.3.1.3 plate,nmaterial316in.(4.76 mm)and over inthickness.3.1.4 sheet and strip,nmaterial under316in.(4.76 mm)inthickness.1This specification is under the jurisdiction of ASTM Committee B02 onNonferrous Metals and Alloys and is the direct responsibility of SubcommitteeB02.07 on Refined Nickel and Cobalt and Their Alloys.Current edition approved June 1,2017.Published June 2017.Originallyapproved in 1972.Last previous edition approved in 2015 as B575 151.DOI:10.1520/B0575-17.2For ASME Boiler and Pressure Vessel Code applications,see related Specifi-cation SB-575 in Section II of that Code.3Designation established in accordance with Practice E527 and SAE J1086,Practice for Numbering Metals and Alloys(UNS).4For referenced ASTM standards,visit the ASTM website,www.astm.org,orcontact ASTM Customer Service at serviceastm.org.For Annual Book of ASTMStandards volume information,refer to the standards Document Summary page onthe ASTM website.*A Summary of Changes section appears at the end of this standardCopyright ASTM International,100 Barr Harbor Drive,PO Box C700,West Conshohocken,PA 19428-2959.United StatesThis international standard was developed in accordance with internationally recognized principles on standardization established in the Decision on Principles for theDevelopment of International Standards,Guides and Recommendations issued by the World Trade Organization Technical Barriers to Trade(TBT)Committee.1 TABLE 1 Chemical RequirementsElementComposition Limits,%AlloyN06035AlloyN06044AlloyN10276AlloyN06022AlloyN06455AlloyN06059AlloyN06058AlloyN06200AlloyN06210AlloyN10362AlloyN06686Molybdenum7.609.000.80-1.2015.017.012.514.514.017.015.016.518.521.015.017.018.020.021.523.015.0-17.0Chromium32.2534.2543.5-45.314.516.520.022.514.018.022.024.020.023.022.024.018.020.013.815.619.0-23.0Iron2.00 max0.3 max4.07.02.06.03.0 max1.5,max1.5,max3.0 max1.0
