温馨提示:
1. 部分包含数学公式或PPT动画的文件,查看预览时可能会显示错乱或异常,文件下载后无此问题,请放心下载。
2. 本文档由用户上传,版权归属用户,汇文网负责整理代发布。如果您对本文档版权有争议请及时联系客服。
3. 下载前请仔细阅读文档内容,确认文档内容符合您的需求后进行下载,若出现内容与标题不符可向本站投诉处理。
4. 下载文档时可能由于网络波动等原因无法下载或下载错误,付费完成后未能成功下载的用户请联系客服处理。
网站客服:3074922707
TM_C_1293_
_08b_2015
Designation:C129308b(Reapproved 2015)Standard Test Method forDetermination of Length Change of Concrete Due to Alkali-Silica Reaction1This standard is issued under the fixed designation C1293;the number immediately following the designation indicates the year oforiginal adoption or,in the case of revision,the year of last revision.A number in parentheses indicates the year of last reapproval.Asuperscript epsilon()indicates an editorial change since the last revision or reapproval.1.Scope*1.1 This test method covers the determination of the sus-ceptibility of an aggregate or combination of an aggregate withpozzolan or slag for participation in expansive alkali-silicareaction by measurement of length change of concrete prisms.1.2 The values stated in SI units are to be regarded as thestandard.No other units of measurement are included in thisstandard.When combined standards are cited,the selection ofmeasurement system is at the users discretion subject to therequirements of the referenced standard.1.3 This standard does not purport to address all of thesafety concerns,if any,associated with its use.It is theresponsibility of the user of this standard to establish appro-priate safety and health practices and determine the applica-bility of regulatory limitations prior to use.(WarningFreshhydraulic cementitious mixtures are caustic and may causechemical burns to skin and tissue upon prolonged exposure.2)2.Referenced Documents2.1 ASTM Standards:3C29/C29M Test Method for Bulk Density(“Unit Weight”)and Voids in AggregateC33 Specification for Concrete AggregatesC125 Terminology Relating to Concrete and Concrete Ag-gregatesC138/C138M Test Method for Density(Unit Weight),Yield,and Air Content(Gravimetric)of ConcreteC143/C143M Test Method for Slump of Hydraulic-CementConcreteC150 Specification for Portland CementC157/C157M Test Method for Length Change of HardenedHydraulic-Cement Mortar and ConcreteC192/C192M Practice for Making and Curing Concrete TestSpecimens in the LaboratoryC227 Test Method for Potential Alkali Reactivity ofCement-Aggregate Combinations(Mortar-Bar Method)C289 Test Method for Potential Alkali-Silica Reactivity ofAggregates(Chemical Method)C294 Descriptive Nomenclature for Constituents of Con-crete AggregatesC295 Guide for Petrographic Examination ofAggregates forConcreteC490 Practice for Use ofApparatus for the Determination ofLength Change of Hardened Cement Paste,Mortar,andConcreteC494/C494M Specification for Chemical Admixtures forConcreteC511 Specification for Mixing Rooms,Moist Cabinets,Moist Rooms,and Water Storage Tanks Used in theTesting of Hydraulic Cements and ConcretesC618 Specification for Coal Fly Ash and Raw or CalcinedNatural Pozzolan for Use in ConcreteC702 Practice for Reducing Samples ofAggregate to TestingSizeC856 Practice for Petrographic Examination of HardenedConcreteC989 Specification for Slag Cement for Use in Concrete andMortarsC1240 Specification for Silica Fume Used in CementitiousMixturesC1260 Test Method for Potential Alkali Reactivity of Ag-gregates(Mortar-Bar Method)D75 Practice for Sampling Aggregates2.2 CSA Standards:4CSA A23.2-14A Potential Expansivity of Aggregates(Pro-cedure for Length Change due to Alkali-Aggregate Reac-tion in Concrete Prisms at 38 C)CSA A23.2-27A Standard Practice to Identify Degree ofAlkali-Reactivity of Aggregates and to Identify Measures1This test method is under the jurisdiction of Committee C09 on Concrete andConcrete Aggregatesand is the direct responsibility of Subcommittee C09.26 onChemical Reactions.Current edition approved Aug.1,2015.Published October 2015.Originallyapproved in 1995.Last previous edition approved in 2008 as C1293 08b.DOI:10.1520/C1293-08BR15.2Section on Safety Precautions,Manual of Aggregate and Concrete Testing,Annual Book of ASTM Standards,Vol.04.02.3For referenced ASTM standards,visit the ASTM website,www.astm.org,orcontact ASTM Customer Service at serviceastm.org.For Annual Book of ASTMStandards volume information,refer to the standards Document Summary page onthe ASTM website.4Available from Canadian Standards Association(CSA),5060 Spectrum Way,Mississauga,ON L4W 5N6,Canada,http:/www.csa.ca.*A Summary of Changes section appears at the end of this standardCopyright ASTM International,100 Barr Harbor Drive,PO Box C700,West Conshohocken,PA 19428-2959.United States1 to Avoid Deleterious Expansion in ConcreteCSAA23.2-28A Standard Practice for Laboratory Testing toDemonstrate the Effectiveness of Supplementary Cement-ing Materials and Lithium-Based Admixtures to PreventAlkali-Silica Reaction in Concrete3.Terminology3.1 Terminology used in this standard is as given in Termi-nology C125 or Descriptive Nomenclature C294.4.Significance and Use4.1 Alkali-silica reaction is a chemical interaction betweensome siliceous constituents of concrete aggregates and hy-droxyl ions(1).5The concentration of hydroxyl ion within theconcrete is predominantly controlled by the concentration ofsodium and potassium(2).4.2 This test method
