-1 NOTICE OF I I AOOPTION I c ADOPTION NOTICE 1 17 November 1988 ASTM D 2417-88 February 1,1988 SUPERSEDING ASTM D 2417-77e 18 May 1981 USED INSTEAD OF SS-P-154Of3,TYPE I ASTM O 2417-88 was adopted on 17 November 1988 and i s approved f o r use by t h e Department o f Defense(Doo).ASTM has furnished clearances required by e x i s t i n g regulations.Philadelphia,PA 19120,f o r issue t o DoD a c t i v i t i e s only.A l l other requestors must obtain documents from:Copies o f t h i s document are stocked by Do0 Single.Stock Point,Naval Publications and Forms Center,5801 Tabor Avenue,ASTM 1916 Race Street Philadelphia,PA 19103 T i t l e o f Document:Standard Specification f o r Perforated,Laminated-Wall Bituminized Fiber Pipe f o r General Drainage Date o f Specific Issue Adopted:February 1,1988 Releasing Non-Government Standards Body:ASTM*NOTE:For Type II,use ASTM D 1862.For Type II,class 2,s t y l e A,use ASTM 02417.Custodians:-Army-ME Navy-YO A i r Force-99 M i l i t a r y Coordinating A c t i v i t y:Navy-YD(Project 5630-01 54)User A c t i v i t i e s:Army-CE Navy-HC FSC 5630 DISTRIBUTION STATEMENT A.Approved f o r public release;d i s t r i b u t i o n i s unlimited.THIS DOCUMENT CONTAINS PAGES.NOTICE:This standard has either been superseded and replaced by a new version or discontinued.Contact ASTM International(www.astm.org)for the latest information.Y ASTM D2437 88 E 0759530 0025445 9 W AMERICAN SOCIETY FOR TESTING AND MATERIALS 1918 Race St.,Philadelphia,Pa.19103 Reprinted from the Annual Bwk of ASTM Standards,Copyrlght ASTM If not listed In the current combined index,wlli appear in the next edition.Standard Specification for Perforated,Laminated-Wall Bituminized Fiber Pipe for General Drainage This standard is issued under the futed designation D 2417;the number immediately following the designation indicates the year of original adoption or,in the cace of revision,fhe year of last revision.A number in parentheses indicates the year of last reapproval.A superscript epsilon(e)indicates an editorial change since the last revision or reapprovai.This specijication has been approved for irse by agencies of the Department of Defense to replace Federal Specijication SS-P-l540B,Type II,Class 2,Style A and for listing in the DoD Index of Specijications and Standards.1.Scope 1.1 This specification covers laminated-wall bituminized fiber perforated drainage pipe for use in agricultural,land,and general drainage.1.2 The values stated in SI units are to be regarded as the standard,2.Referenced Document 2.1 ASTM Standard:D 23 15 Methods of Testing Laminated-Wail Bituminized Fiber Pipe2 3.Materials and Manufacture 3.1 Pipe and Couplings-Pipe and couplings shall be composed of a multi-ply laminated convolute or spiral fibrous structure,with the laminations being adhered with a heat-and water-resistant adhesive and then thoroughy impregnated with a bituminous compound.The pipe shall have a smooth interior surface free of obstructions and rough or flaky areas.Bends,fittings and adapters shali be of the same material as the pipe,or of a material having equal or better physical and chemical properties.3.2 Joint Systems-Pipe and fittings shall use either of the following joint systems:3.2.1 Type TJ Joints-Pipe and fittings shall be provided with accurately machined or molded tapered joints,and a taper-sleeve coupling shall be provided for each length of pipe and for each fitting where applicable.The slope of the taper in both pipe and coupling shall be 2(4 including angle)(see Fig.1).3.2.2 Type BJ Joints-Pipe and fittings shall have squarely cut ends,and a split-collar coupling shall be provided for each length of pipe and for each fitting where applicable(see Fig.2).4.Physical and Chemical Requirements 4.1 Resistance to Flattening-The requirements for resist-ance to flattening shall be that the decrease in diameter shall not exceed 3%,when loaded with 1460 N/m(100 lbf/ft).This specification is under the jurisdiction of ASTM Committee D-8 on Roofing,Waterproofing,and Bituminous Materiais and is the direcf responsibility of Subcommittee W8.16 on Bituminized Fiber Pipe.Current edition approved Feb.1,1988.Published April 1988.Originally published as D 2417-65 T.iast previous edition D 2417-77(1981).Annual Book o f ASTM Standards,Vol 04.04.4.2 Crushing Strengths-The pipe shall have a minimum three-edge-bearing crushing strength of 13.I kN/m(900 lbf/ft)(wet and dry).4.3 Wafer Absorption-The maximum water absorption shall be 2%of the original weight.4.4 Boiling Water Resistance-Specimens shall exhibit not less than 90%of the crushing strength.4.5 Heat Resistance-The heat shall not cause a weight loss over 1%in the specimen due to the exudation of the impregnant.4.6 Chemical Resistance-Specimens shall show no vis-ible sign of chemical reaction or deterioration of the im-pregnant.4.7 Kerosine Resistance-Specimens shall meet the crushing strength requirements,5.Dimensions 5.1 Pipe and Couplings-The dimensions of the pipe and cou
