Designation:D268001(Reapproved 2014)Standard Specification forAcrylonitrile-Butadiene-Styrene(ABS)and Poly(VinylChloride)(PVC)Composite Sewer Piping1This standard is issued under the fixed designation D2680;the number immediately following the designation indicates the year oforiginal adoption or,in the case of revision,the year of last revision.A number in parentheses indicates the year of last reapproval.Asuperscript epsilon()indicates an editorial change since the last revision or reapproval.1.Scope1.1 This specification covers thermoplastic composite pipe,fittings and a joining system for use in gravity flow,nonpres-sure sanitary sewer,and storm drain installations.The pipe andfittings are made of ABS or PVC plastic material.Recom-mended installation practices are referenced in Appendix X1.1.2 The values stated in inch-pound units are to be regardedas standard.The values given in parentheses are mathematicalconversions to SI units that are provided for information onlyand are not considered standard.1.3 The following safety hazards caveat pertains only to thetest method portion,Section 10,of this specification:Thisstandard does not purport to address all of the safety problems,if any,associated with its use.It is the responsibility of the userof this standard to establish appropriate safety and healthpractices and determine the applicability of regulatory limita-tions prior to use.Specific precautionary information is givenin 7.2.4.2.Referenced Documents2.1 ASTM Standards:2D618 Practice for Conditioning Plastics for TestingD1084 Test Methods for Viscosity of AdhesivesD1600 Terminology forAbbreviated Terms Relating to Plas-ticsD1784 Specification for Rigid Poly(Vinyl Chloride)(PVC)Compounds and Chlorinated Poly(Vinyl Chloride)(CPVC)CompoundsD2122 Test Method for Determining Dimensions of Ther-moplastic Pipe and FittingsD2152 Test Method for Adequacy of Fusion of ExtrudedPoly(Vinyl Chloride)(PVC)Pipe and Molded Fittings byAcetone ImmersionD2235 Specification for Solvent Cement for Acrylonitrile-Butadiene-Styrene(ABS)Plastic Pipe and FittingsD2321 Practice for Underground Installation of Thermoplas-tic Pipe for Sewers and Other Gravity-Flow ApplicationsD2412 Test Method for Determination of External LoadingCharacteristics of Plastic Pipe by Parallel-Plate LoadingD2564 Specification for Solvent Cements for Poly(VinylChloride)(PVC)Plastic Piping SystemsD3138 Specification for Solvent Cements for TransitionJoints Between Acrylonitrile-Butadiene-Styrene(ABS)and Poly(Vinyl Chloride)(PVC)Non-Pressure PipingComponentsD3212 Specification for Joints for Drain and Sewer PlasticPipes Using Flexible Elastomeric SealsD3965 Classification System and Basis for Specifications forRigid Acrylonitrile-Butadiene-Styrene(ABS)Materialsfor Pipe and FittingsD4396 Specification for Rigid Poly(Vinyl Chloride)(PVC)and Chlorinated Poly(Vinyl Chloride)(CPVC)Com-pounds for Plastic Pipe and Fittings Used in NonpressureApplications(Withdrawn 2015)3F402 Practice for Safe Handling of Solvent Cements,Primers,and Cleaners Used for Joining ThermoplasticPipe and FittingsF412 Terminology Relating to Plastic Piping SystemsF477 Specification for Elastomeric Seals(Gaskets)for Join-ing Plastic PipeF913 Specification for Thermoplastic Elastomeric Seals(Gaskets)for Joining Plastic Pipe2.2 Federal Standard:Fed.Std.No.123 Marking for Shipment(Civil Agencies)42.3 Military Standard:MIL-STD-129 Marking for Shipment and Storage43.Terminology3.1 Definitions:1This specification is under the jurisdiction of ASTM Committee F17 on PlasticPiping Systems and is the direct responsibility of Subcommittee F17.62 on Sewer.Current edition approved Aug.1,2014.Published November 2014.Originallypublished as D2680 68 T.Last previous edition approved in 2009 asD2680 01(2009).DOI:10.1520/D2680-01R14.2For referenced ASTM standards,visit the ASTM website,www.astm.org,orcontact ASTM Customer Service at serviceastm.org.For Annual Book of ASTMStandards volume information,refer to the standards Document Summary page onthe ASTM website.3The last approved version of this historical standard is referenced onwww.astm.org.4Available from Standardization Documents Order Desk,DODSSP,Bldg.4,SectionD,700RobbinsAve.,Philadelphia,PA19111-5098,http:/www.dodssp.daps.mil.Copyright ASTM International,100 Barr Harbor Drive,PO Box C700,West Conshohocken,PA 19428-2959.United States1 3.1.1 GeneralDefinitions are in accordance with Termi-nology F412 and abbreviations are in accordance with Termi-nology D1600,unless otherwise specified.The abbreviation foracrylonitrile-butadiene-styrene isABS and the abbreviation forpoly(vinyl chloride)is PVC.3.2 Definitions of Terms Specific to This Standard:3.2.1 acrylonitrile-butadiene-styrene(ABS)plastics con-taining polymers or blends of polymers,or both,in which theminimum butadiene content is 6%;the minimum acrylonitrilecontent is 15%;the minimum styrene or substituted styrenecontent,or both,is 15%;and the maximum content of all othermonomers is not more than
