Designation:D4917 97(Reapproved 2007)1An American National StandardStandard Test Method forCoefficient of Static and Kinetic Friction of UncoatedWriting and Printing Paper by Use of the Horizontal PlaneMethod1This standard is issued under the fixed designation D4917;the number immediately following the designation indicates the year oforiginal adoption or,in the case of revision,the year of last revision.A number in parentheses indicates the year of last reapproval.Asuperscript epsilon()indicates an editorial change since the last revision or reapproval.1NOTEThe research report number in footnote 5 was editorially corrected in November 2008.1.Scope1.1 This test method describes a horizontal plane procedurefor the determination of the coefficient of static and kineticfriction of paper measured when sliding against itself.1.2 Although this test method is basic in concept,theprecision statement has been developed on uncoated writingand printing papers.While the use of this test method isrecommended for those grades only,it may be used with othertypes of papers giving specific attention to special papercharacteristics and with the understanding that the precisionand bias may not be the same.1.3 The horizontal instrument requires some means ofmovement of the specimen in relation to the surface uponwhich it rests.The coefficient of friction(COF)is measureddirectly from the resistance to tangential motion and theapplied weight pressing two pieces of paper together.1.4 Static COF relates to the force required to initiatemovement between two surfaces while kinetic COF relates tothe force required to cause continuation of the movement atuniform speed.1.5 An inclined plane method is described in Test MethodD4918,which gives similar results for static COF but TestMethod D4918 cannot be used for the determination of kineticCOF.The choice of approach depends on the equipmentavailable and the means of measurement.1.6 The determination of this characteristic for corrugatedand solid fiberboard is described in Test Methods D4521 andD3247.These test methods differ in that in Test MethodsD4521 and D3247,the two specimens are allowed to slip uponone another three times before the force measurement isdetermined,while in this test method the determination is madeon the first slip.1.7 This standard does not purport to address all of thesafety concerns,if any,associated with its use.It is theresponsibility of the user of this standard to establish appro-priate safety and health practices and determine the applica-bility of regulatory limitations prior to use.2.Referenced Documents2.1 ASTM Standards:2D528 Test Method for Machine Direction of Paper andPaperboardD585 Practice for Sampling and Accepting a Single Lot ofPaper,Paperboard,Fiberboard,and Related ProductD685 Practice for Conditioning Paper and Paper Productsfor Testing3D725Discontinued 1980;Method for Identification ofWire Side of Paper;Reinstated 1990 as D 50393D828 Test Method for Tensile Properties of Paper andPaperboard Using Constant-Rate-of-Elongation Appara-tus3D1968 Terminology Relating to Paper and Paper ProductsD3247 Method of Test for Coefficient of Static Friction ofCorrugated and Solid Fiberboard(Horizontal PlaneMethod)3D3460 Specification for White Watermarked and Unwater-marked Bond,Reprographic,and Laser Printer Cut-SizedOffice Papers3D4521 Test Method for Coefficient of Static Friction ofCorrugated and Solid Fiberboard(Discontinued 2001)3D4918 Test Method for Coefficient of Static Friction ofUncoated Writing and Printing Paper by Use of theInclined Plane Method1This test method is under the jurisdiction of ASTM Committee D06 on Paperand Paper Products and is the direct responsibility of Subcommittee D06.92 onStandard Documents Relating to Paper and Paper Products.Current edition approved April 1,2007.Published May 2007.Originallyapproved in 1989.Last previous edition approved in 2002 as D4917 97(2002).DOI:10.1520/D4917-97R07E01.2For referenced ASTM standards,visit the ASTM website,www.astm.org,orcontact ASTM Customer Service at serviceastm.org.For Annual Book of ASTMStandards volume information,refer to the standards Document Summary page onthe ASTM website.3Withdrawn.1Copyright ASTM International,100 Barr Harbor Drive,PO Box C700,West Conshohocken,PA 19428-2959,United States.NOTICE:This standard has either been superseded and replaced by a new version or withdrawn.Contact ASTM International(www.astm.org)for the latest informationE122 Practice for Calculating Sample Size to Estimate,With Specified Precision,the Average for a Characteristicof a Lot or Process3.Terminology3.1 DefinitionsDefinitions shall be in accordance withTerminology D1968 and the Dictionary of Paper.44.Summary of Test Method4.1 One specimen of the paper sample is clamped to ahorizontal plane surface,the other to a specimen sled.The sledis pulled across the surface,or alternatively,the plane is pulledunder the stationary sled by mechanical means,and the forcerequired to do so is measured.Th
