Designation:E 1117 97Standard Practice forDesign of Fuel-Alcohol Manufacturing Facilities1This standard is issued under the fixed designation E 1117;the number immediately following the designation indicates the year oforiginal adoption or,in the case of revision,the year of last revision.A number in parentheses indicates the year of last reapproval.Asuperscript epsilon(e)indicates an editorial change since the last revision or reapproval.1.Scope1.1 This practice shall apply to all fuel alcohol manufactur-ing facilities(FAMF)as defined in Terminology E 1705.Thisspecification is primarily intended for,but not exclusivelylimited to fermentation ethanol processes.1.2 This practice applies to both batch and continuousFAMF systems.Since a wide variety of equipment configura-tions can exist,this engineering practice will describe thenecessary general requirements common to all FAMF facili-ties.1.3 This practice is to be used in conjunction with appli-cable local,state,and Federal codes for designing,construct-ing,and operating FAMF facilities.1.4 The values stated in SI units are to be regarded as thestandard.The values given in parentheses are for informationonly.1.5 This standard does not purport to address all of thesafety concerns,if any,associated with its use.It is theresponsibility of the user of this standard to establish appro-priate safety and health practices and determine the applica-bility of regulatory limitations prior to use.For hazard state-ment,see Section 11.2.Referenced Documents2.1 ASTM Standards:E 1705 Terminology Relating to Biotechnology22.2ANSI Standard:Z21.22 Relief Valves and Automatic Shut-Off Devices forHot Water Supply Systems32.3ASME Standard:Boiler Construction Codes,Sections I,IV,VII,and VIII42.4Code of Federal Regulations Standard:Bureau ofAlcohol,Tax,and Firearms(BATF),Part 19,Title27,Chapter 152.5NFPA Standard:85A Prevention of Furnace Explosions in Fuel Oil andNatural Gas-Fired Single Burner Boiler-Furnaces63.Terminology3.1 Definitions of Terms Specific to This Standard:3.1.1 accessible,npermitting close approach or contactthat could include requiring removal or opening of an accesspanel or door.3.1.2 durability,nthe quality of a component to performas designed for its design life.3.1.3 extreme weather conditions,nenvironmental condi-tions that have occurred only once during the past 30 years.3.1.4 good engineering practices,ninclude design prac-tices and criteria accepted in professional societies(ASTM,AIChE,ASME,ACS,etc.),proved by experience,verified byactual data,etc.,that will meet the process,safety,andenvironmental requirements of the system.3.1.5 normal operating conditions,nthe usual range ofphysical operating conditions(flow,pressure,temperature,etc.)for component or system.3.1.6 normal weather conditions,nthe range of environ-mental conditions in a local climatic region that occurredduring the past 30 years.This excludes extreme conditions thathave occurred only once during that period.4.Summary of Practice4.1 The following procedures described provide minimumpractices to be used in designing,constructing,operating,andmodifying fuel alcohol manufacturing facilities.These prac-tices are to provide guidelines that incorporate good engineer-ing practices for personnel and organizations engaged in theseFAMF activities.4.2 These minimum practices are summarized in the follow-ing general categories of equipment as applicable:4.2.1 Vessels and TowersCookers,fermenters,distillationstills,tanks,etc.(see Section 6).4.2.2 Heat-Exchange EquipmentExchangers,condensers,etc.(see Section 7).4.2.3 Rotating EquipmentPumps,blowers,compressors,fans,centrifuges,etc.(see Section 8).4.2.4 ElectricalMotors,motor controls,etc.(see Section9).1This practice is under the jurisdiction of ASTM Committee E-48 on Biotech-nology and is the direct responsibility of Subcommittee E48.05 on BiomassConversion Systems.Current edition approved April 10,1997.Published June 1997.Originallypublished as E 1117 86.Last previous edition E 1117 86(1990).2Annual Book of ASTM Standards,Vol 11.05.3Available from American National Standards Institute,11 West 42nd Street,13th Floor,New York,NY 10036.4Available from American Society of Mechanical Engineers,345 E.47th St.,New York,NY 10017.5Available from the Superintendent of Documents,U.S.Government PrintingOffice,Washington,DC 20402.6Available from National Fire Protection Assoc.,Batterymarch Park,Quincy,MA 02269.1Copyright ASTM,100 Barr Harbor Drive,West Conshohocken,PA 19428-2959,United States.4.2.5 Instruments,ControlsSensing and controlling de-vices,computers,processors,etc.(see Section 10).4.2.6 SafetyPressure relief devices,equipment allowancesfor corrosion,pressure and temperature,personnel safety,etc.(see Section 11).4.2.7 EnvironmentalSolids,water,and air emissions(seeSection 12).4.2.8 UtilitiesBoilers,power distribution,fresh water,air,etc.(see Section 13).4.2.9 PipingPipe,valves,insulation,etc.(see Section 14).4.2.10 Quality ControlFAMF equipment performa
