ASME B18.2.3.9M-2001Revision of ASME B18.2.3.9M-1984(R1995)METRIC HEAVYHEX FLANGESCREWSA N A M E R I C A N N A T I O N A LS T A N D A R DASME B18.2.3.9M-2001Revision of ANSI/ASME B18.2.3.9M-1984(R1995)METRIC HEAVYHEX FLANGESCREWSA N A M E R I C A N N A T I O N A LS T A N D A R DREAFFIRMED 2014FOR CURRENT COMMITTEE PERSONNELPLEASE E-MAIL CSasme.orgIntentionally left blankAN AMERICAN NA TIONALST ANDARDMETRIC HEAVYHEX FLANGESCREWSASME B18.2.3.9M-2001Revision of ANSI/ASME B18.2.3.9M-1984(R1995)Date of Issuance:September 17,2001This Standard will be revised when the Society approves the issuance of anew edition.There will be no addenda issued to this edition.ASME will issue written replies to inquiries concerning interpretations oftechnical aspects of this Standard.ASME is the registered trademark of The American Society of Mechanical Engineers.This code or standard was developed under procedures accredited as meeting the criteria forAmerican National Standards.The Standards Committee that approved the code or standardwas balanced to assure that individuals from competent and concerned interests have had anopportunity to participate.The proposed code or standard was made available for public reviewand comment that provides an opportunity for additional public input from industry,academia,regulatory agencies,and the public-at-large.ASME does not“approve,”“rate,”or“endorse”any item,construction,proprietary device,or activity.ASME does not take any position with respect to the validity of any patent rights asserted inconnection withany itemsmentioned inthis document,and doesnot undertaketo insureanyoneutilizing a standard against liability for infringement of any applicable letters patent,nor assumeany such liability.Users of a code or standard are expressly advised that determination of thevalidity of any such patent rights,and the risk of infringement of such rights,is entirely theirown responsibility.Participation by federal agency representative(s)or person(s)affiliated with industry is not tobe interpreted as government or industry endorsement of this code or standard.ASME accepts responsibility for only those interpretations of this document issued inaccordance with the established ASME procedures and policies,which precludes the issuanceof interpretations by individuals.No part of this document may be reproduced in any form,in an electronic retrieval system or otherwise,without the prior written permission of the publisher.The American Society of Mechanical EngineersThree Park Avenue,New York,NY 10016-5990Copyright 2001 byTHE AMERICAN SOCIETY OF MECHANICAL ENGINEERSAll Rights ReservedPrinted in U.S.A.FOREWORDAmerican National Standards Committee B18 for the standardization of bolts,screws,nuts,rivets,and similar fasteners was organized in March 1922 as Sectional CommitteeB18 under the aegis of the American Engineering Standards Committee(later the AmericanStandards Association,then the United States of America Standards Institute and,as ofOctober 6,1969,the American National Standards Institute,Inc.),with the Society ofAutomotive Engineers and the American Society of Mechanical Engineers as joint sponsors.Subcommittee 2 was subsequently established and charged with the responsibility for technicalcontent of standards covering wrench head bolts and nuts.At its meeting on December 4,1974,Committee B18 authorized preparation of a seriesof standards for metric fasteners.Subcommittee 2 was assigned responsibility for developingstandards for metric hex bolts,screws,and nuts.Following issuance of ANSI B18.2.3.4M-1979,interest developed in the farm equipment,heavy truck,and off-road vehicles industries for a second series of metric hex flange screwshaving a head widths across flats series equal to those of metric hex cap screws.Duringthe analytical research study to optimize head proportions of hex flange screws(refer tothe Foreword of ASME B18.2.3.4M-2000),this larger head series was also investigated,and appropriate values for the various head characteristics were established for screw sizesM10 through M20.This new design of metric heavy hex flange screws was submitted by the United Statesof America/Canada to ISO/TC2 at its May 1982 meetings.TC2 accepted the proposal andauthorized development of International Organization for Standardization(ISO)standards.After these ISO decisions,Subcommittee 2 drafted this Standard.This Standard was approved by letter ballot of the ASME B18 Standards Committee onApril 18,1983,and was subsequently approved by the American Society of MechanicalEngineers and submitted to the American National Standards Institute for designation asan American National Standard.This was granted on March 23,1984.The Standard wasreaffirmed in 1995.This draft revision was prepared based on revisions that were made inthe metric hex cap screw standard in December 1998.This Standard was approved by theAmerican National Standards Institute on March 9,2001.The key revisions include thefollowing:(a)The heavy
